Adding the Deleted Flag #

The first step in our refactor will be to update every table we want to soft delete to add a new column. This will be the flag that determines whether the record is deleted or not. You can use just a boolean here, however this is an opportunity for us to capture more data and potentially make debugging a bit easier. I prefer using a nullable timestamp for my flag - null signifies it is not deleted, whereas the presence of a date indicates not only that it was deleted, but also when. Because soft deletion is commonly used to support internal reporting scenarios, this can sometimes be quite useful information.

Adding the column is quite straightforward of course, it can be added with no effect on the overall system:

ALTER TABLE items ADD COLUMN deleted TIMESTAMP DEFAULT NULL;
ALTER TABLE carts ADD COLUMN deleted TIMESTAMP DEFAULT NULL;
ALTER TABLE cart_items ADD COLUMN deleted TIMESTAMP DEFAULT NULL;
-- https://github.com/IanWold/PostgresRefactorSoftDelete/blob/main/SingleTableMigration.cs#L6
ALTER TABLE items ADD COLUMN deleted TIMESTAMP DEFAULT NULL;
ALTER TABLE carts ADD COLUMN deleted TIMESTAMP DEFAULT NULL;
ALTER TABLE cart_items ADD COLUMN deleted TIMESTAMP DEFAULT NULL;
-- https://github.com/IanWold/PostgresRefactorSoftDelete/blob/main/SingleTableMigration.cs#L6 [tl! autolink]

This can be deployed at any time and will not affect the rest of the system unless you're doing something squirrely with your tables. Just note though that if there's a long gap between your migration steps, new tables should have this column included. Because this column isn't used, it will be null for all records, and until we proceed to the next steps records will still be hard deleted.

Hiding Deleted Data #

This second step can also be deployed at any time after the first step with no change in the functionality of the system: we're going to hide any data where deleted is not null. In order to accomplish this without needing to rewrite any of our queries, constraints, or the like, we'll use views to achieve this.

For the unfamiliar, views act just like tables, but are essentially projections of other underlying tables and views. You define them with a SELECT statement just as you would query any other data. This allows you to marry commonly-referenced data together, but in our case we're going to use them a bit differently.

For each table which has a deleted column, we're going to define a new view which excludes the deleted values of the underlying column. Now, because we have how many references to the tables named items, carts, and cart_items, and it's these references from which we want to exclude the deleted items, we're going to give our views the names of the current tables and rename the current tables.

ALTER TABLE items RENAME TO items_all;
CREATE VIEW items AS SELECT * FROM items_all WHERE deleted IS NULL;
ALTER TABLE carts RENAME TO carts_all;
CREATE VIEW carts AS SELECT * FROM carts_all WHERE deleted IS NULL;
ALTER TABLE cart_items RENAME TO cart_items_all;
CREATE VIEW cart_items AS SELECT * FROM cart_items_all WHERE deleted IS NULL;
-- https://github.com/IanWold/PostgresRefactorSoftDelete/blob/main/SingleTableMigration.cs#L12
ALTER TABLE items RENAME TO items_all;
CREATE VIEW items AS SELECT * FROM items_all WHERE deleted IS NULL;
ALTER TABLE carts RENAME TO carts_all;
CREATE VIEW carts AS SELECT * FROM carts_all WHERE deleted IS NULL;
ALTER TABLE cart_items RENAME TO cart_items_all;
CREATE VIEW cart_items AS SELECT * FROM cart_items_all WHERE deleted IS NULL;
-- https://github.com/IanWold/PostgresRefactorSoftDelete/blob/main/SingleTableMigration.cs#L12 [tl! autolink]

Here I use the convention that the table name is suffixed "_all", signifying of course that the tables contain "all" of the records. Your requirements might be different, so pick a naming convention that makes sense in the context. I recommend being extremely consistent here, and I also recommend picking a convention that is obvious in distinguishing the tables.

After deploying this update, you'll find that your system is still working exactly as it has in the past. Postgres passes any commands on these views down to the underlying table, so when you INSERT into one of these views, the data will be inserted into its respective table. Neat!

Make Deletes Not Delete #

This is the crucial step now: we need to redefine what a "delete" means. While the last two steps alter neither the behavior of the system nor the representation, this step will alter the representation of the data, and so long as we're dilligent it will not alter the behavior for your users. Because you're altering the data representation now though, be careful!

There's two steps we need to take here at once. First, we need to tell Postgres that when it gets a DELETE command for one of these tables that it actually needs to update the deleted column instead. Second, we need to define the new cascade behaviors to propogate the soft deletion in the intended way.

To redefine DELETE, Potgres allows us to create a rule to perform an alternate action instead. Typical for Postgres, this syntax is quite straightforward:

CREATE RULE rule_soft_delete AS ON DELETE TO items DO INSTEAD (UPDATE items_all SET deleted = CURRENT_TIMESTAMP WHERE item_id = OLD.item_id);
CREATE RULE rule_soft_delete AS ON DELETE TO carts DO INSTEAD (UPDATE carts_all SET deleted = CURRENT_TIMESTAMP WHERE cart_id = OLD.cart_id);
CREATE RULE rule_soft_delete AS ON DELETE TO cart_items DO INSTEAD (UPDATE cart_items_all SET deleted = CURRENT_TIMESTAMP WHERE cart_item_id = OLD.cart_item_id);
-- https://github.com/IanWold/PostgresRefactorSoftDelete/blob/main/SingleTableMigration.cs#L23
CREATE RULE rule_soft_delete AS ON DELETE TO items DO INSTEAD (UPDATE items_all SET deleted = CURRENT_TIMESTAMP WHERE item_id = OLD.item_id);
CREATE RULE rule_soft_delete AS ON DELETE TO carts DO INSTEAD (UPDATE carts_all SET deleted = CURRENT_TIMESTAMP WHERE cart_id = OLD.cart_id);
CREATE RULE rule_soft_delete AS ON DELETE TO cart_items DO INSTEAD (UPDATE cart_items_all SET deleted = CURRENT_TIMESTAMP WHERE cart_item_id = OLD.cart_item_id);
-- https://github.com/IanWold/PostgresRefactorSoftDelete/blob/main/SingleTableMigration.cs#L23 [tl! autolink]

And then we need to handle the cascades. Let's start with the simple case where we know that deleting a cart should cascade to each of its items. The rule we define will act on updates to the carts_all table and propogate new, non-null values for deleted to the cart items:

CREATE RULE rule_cascade_deleted_cart_items AS ON UPDATE TO carts_all
    WHERE OLD.deleted IS DISTINCT FROM NEW.deleted
    DO ALSO UPDATE cart_items_all SET deleted = NEW.deleted WHERE cart_id = OLD.cart_id;
-- https://github.com/IanWold/PostgresRefactorSoftDelete/blob/main/SingleTableMigration.cs#L27
CREATE RULE rule_cascade_deleted_cart_items AS ON UPDATE TO carts_all
    WHERE OLD.deleted IS DISTINCT FROM NEW.deleted
    DO ALSO UPDATE cart_items_all SET deleted = NEW.deleted WHERE cart_id = OLD.cart_id;
-- https://github.com/IanWold/PostgresRefactorSoftDelete/blob/main/SingleTableMigration.cs#L27 [tl! autolink]

Recall that the other cascade case, where we delete an item, is more complicated. The current behavior (which we are just trying to preserve for now) is that items are deleted from a cart when the items themselves are deleted. The state we want to achieve (some time after this migration) is that items will still show in the cart but as "no longer available". That will take some extra coding to implement, however depending on the current state of our system we might be able to achieve some cost savings.

If you just want to keep the refactor simple or your system wouldn't currently support an alternate scheme, then you can implement the exact same rule but for items, then remove it later once you're ready. However, consider whether your current system would be able to do without the cascade right off the bat here. Suppose you have some logic on your cart page which attempts to get item data for all items in the cart and will not display items for which it cannot find data. In this case, you do not need to add the cascade, and the users will still observe the same behavior they currently have!

If you do decide not to carry over the cascade, there is the matter of the foreign key reference - if we soft delete a record from the items_all table, the foreign key on cart_items.item_id is still referencing the new items view and will break! In this case, we'll need to update the foreign key now:

ALTER TABLE cart_items_all DROP CONSTRAINT fk_item;
ALTER TABLE cart_items_all ADD CONSTRAINT fk_items_all FOREIGN KEY (item_id) REFERENCES items_all (item_id) ON DELETE CASCADE;
ALTER TABLE cart_items_all DROP CONSTRAINT fk_item;
ALTER TABLE cart_items_all ADD CONSTRAINT fk_items_all FOREIGN KEY (item_id) REFERENCES items_all (item_id) ON DELETE CASCADE;

Again, this step does not need to be done now if you are adding the manual cascade for items.

Accessing Deleted Records #

At this point, your migration is finished. Congratulations! In order to get records that have been deleted, you just need to query the _all table for that record:

SELECT * FROM items_all WHERE ...
-- https://github.com/IanWold/PostgresRefactorSoftDelete/blob/main/SingleTableMigration.cs#L37
SELECT * FROM items_all WHERE ...
-- https://github.com/IanWold/PostgresRefactorSoftDelete/blob/main/SingleTableMigration.cs#L37 [tl! autolink]

In order to hard delete any records, you can DELETE from the _all table:

DELETE FROM items_all WHERE ...
DELETE FROM items_all WHERE ...

Adding the Deleted Tables #

The first step in our refactor will be to add a corresponding table for each existing table that will include the deleted fields. Instead of adding a deleted timestamp on the main table itself, it's sufficient for only this copy table to contain the field. We'll use LIKE to copy the schema of the base tables.

CREATE TABLE items_deleted (
    deleted TIMESTAMP DEFAULT CURRENT_TIMESTAMP,
    LIKE items INCLUDING ALL
);
CREATE TABLE carts_deleted (
    deleted TIMESTAMP DEFAULT CURRENT_TIMESTAMP,
    LIKE carts INCLUDING ALL
);
CREATE TABLE cart_items_deleted (
    deleted TIMESTAMP DEFAULT CURRENT_TIMESTAMP,
    LIKE cart_items INCLUDING ALL
);
-- https://github.com/IanWold/PostgresRefactorSoftDelete/blob/main/SeparateTableMigration.cs#L6
CREATE TABLE items_deleted (
    deleted TIMESTAMP DEFAULT CURRENT_TIMESTAMP,
    LIKE items INCLUDING ALL
);
CREATE TABLE carts_deleted (
    deleted TIMESTAMP DEFAULT CURRENT_TIMESTAMP,
    LIKE carts INCLUDING ALL
);
CREATE TABLE cart_items_deleted (
    deleted TIMESTAMP DEFAULT CURRENT_TIMESTAMP,
    LIKE cart_items INCLUDING ALL
);
-- https://github.com/IanWold/PostgresRefactorSoftDelete/blob/main/SeparateTableMigration.cs#L6 [tl! autolink]

My same note from earlier about naming conventions applies, though I think _deleted is probably the suffix 99% of us will ever use for these.

There is one issue with this snippet though - can you spot it? The problem is in cart_items_deleted: LIKE ... INCLUDING ALL will copy over the entire table schema, foreign key references included. In order to get around this, we'll need to not use INCLUDING ALL and manually copy over the foreign key constraints:

CREATE TABLE cart_items_deleted (
    deleted TIMESTAMP DEFAULT CURRENT_TIMESTAMP,
    LIKE cart_items,
    CONSTRAINT fk_cart FOREIGN KEY (cart_id) REFERENCES carts_deleted (cart_id) ON DELETE CASCADE,
    CONSTRAINT fk_item FOREIGN KEY (item_id) REFERENCES items_deleted (item_id) ON DELETE CASCADE
);
CREATE TABLE cart_items_deleted (
    deleted TIMESTAMP DEFAULT CURRENT_TIMESTAMP,
    LIKE cart_items,
    CONSTRAINT fk_cart FOREIGN KEY (cart_id) REFERENCES carts_deleted (cart_id) ON DELETE CASCADE,
    CONSTRAINT fk_item FOREIGN KEY (item_id) REFERENCES items_deleted (item_id) ON DELETE CASCADE
);

But wait, there's more! This works all well and good so long as the carts and items you're referencing from the cart_items_deleted table actually exist in items_deleted and carts_deleted. This is sure to not be the case, as it makes perfect sense that I might delete a cart item without that item having been deleted! Supposing that we did have a schema where we would expect the referant to be deleted also though, are we sure that that record is being deleted first?

This can all get quite tricky. If you don't care about the referential integrity of your soft-delted data (but trust me, you probably should), then you can just forego the foreign key constraints. If you do care about the references though, then you'll need to spend some time thinking about the best approach here. A whole article can be written on potential approaches so I won't distract us here, but beware of this trap!

This demonstrates the extra complexity of this second approach. It allows for a greater separation between deleted and non-deleted items, though it's important to consider which functionality and level of complexity your system requires.

Adding the Combined Views #

There are inevitably operations we're going to want to perform on the whole dataset for each table - deleted and non-deleted items all as one. To facilitate this, we'll create a view for each table/deleted table pair which unions the two:

CREATE VIEW items_combined AS SELECT null AS deleted, * FROM items UNION ALL SELECT * FROM items_deleted;
CREATE VIEW carts_combined AS SELECT null AS deleted, * FROM carts UNION ALL SELECT * FROM carts_deleted;
CREATE VIEW cart_items_combined AS SELECT null AS deleted, * FROM cart_items UNION ALL SELECT * FROM cart_items_deleted;
-- https://github.com/IanWold/PostgresRefactorSoftDelete/blob/main/SeparateTableMigration.cs#L23
CREATE VIEW items_combined AS SELECT null AS deleted, * FROM items UNION ALL SELECT * FROM items_deleted;
CREATE VIEW carts_combined AS SELECT null AS deleted, * FROM carts UNION ALL SELECT * FROM carts_deleted;
CREATE VIEW cart_items_combined AS SELECT null AS deleted, * FROM cart_items UNION ALL SELECT * FROM cart_items_deleted;
-- https://github.com/IanWold/PostgresRefactorSoftDelete/blob/main/SeparateTableMigration.cs#L23 [tl! autolink]

At least that's easy!

Make Delete Not Delete #

In order to make DELETEs perform a soft delete in this setup, we need to do a couple things when deleting: first, we need to copy the record into the respective _deleted table, then we need to allow the delete to actually happen.

Here we have a couple options. We could use a RULE...DO ALSO to perform the insert after the delete:

CREATE RULE soft_delete AS ON DELETE TO items DO ALSO (
    INSERT INTO items_deleted (item_id, name, price, created)
    VALUES (OLD.item_id, OLD.name, OLD.price, OLD.created)
);
CREATE RULE soft_delete AS ON DELETE TO carts DO ALSO (
    INSERT INTO carts_deleted (cart_id, user_id, created)
    VALUES (OLD.cart_id, OLD.user_id, OLD.created)
);
CREATE RULE soft_delete AS ON DELETE TO cart_items DO ALSO (
    INSERT INTO cart_items_deleted (cart_item_id, cart_id, item_id, quantity, created)
    VALUES (OLD.cart_item_id, OLD.cart_id, OLD.item_id, OLD.quantity, OLD.created)
);
CREATE RULE soft_delete AS ON DELETE TO items DO ALSO (
    INSERT INTO items_deleted (item_id, name, price, created)
    VALUES (OLD.item_id, OLD.name, OLD.price, OLD.created)
);
CREATE RULE soft_delete AS ON DELETE TO carts DO ALSO (
    INSERT INTO carts_deleted (cart_id, user_id, created)
    VALUES (OLD.cart_id, OLD.user_id, OLD.created)
);
CREATE RULE soft_delete AS ON DELETE TO cart_items DO ALSO (
    INSERT INTO cart_items_deleted (cart_item_id, cart_id, item_id, quantity, created)
    VALUES (OLD.cart_item_id, OLD.cart_id, OLD.item_id, OLD.quantity, OLD.created)
);

However, because we're combining operations I would tend towards preferring a trigger in this specific scenario:

CREATE OR REPLACE FUNCTION items_soft_delete() RETURNS TRIGGER AS $$
BEGIN
    INSERT INTO items_deleted (item_id, name, price, created)
    VALUES (OLD.item_id, OLD.name, OLD.price, OLD.created);
    RETURN OLD;
END;
$$ LANGUAGE plpgsql;
CREATE TRIGGER trigger_items_delete BEFORE DELETE ON items FOR EACH ROW EXECUTE FUNCTION items_soft_delete();
CREATE OR REPLACE FUNCTION carts_soft_delete() RETURNS TRIGGER AS $$
BEGIN
    INSERT INTO carts_deleted (cart_id, user_id, created)
    VALUES (OLD.cart_id, OLD.user_id, OLD.created);
    RETURN OLD;
END;
$$ LANGUAGE plpgsql;
CREATE TRIGGER trigger_carts_delete BEFORE DELETE ON carts FOR EACH ROW EXECUTE FUNCTION carts_soft_delete();
CREATE OR REPLACE FUNCTION cart_items_soft_delete() RETURNS TRIGGER AS $$
BEGIN
    INSERT INTO cart_items_deleted (cart_item_id, cart_id, item_id, quantity, created)
    VALUES (OLD.cart_item_id, OLD.cart_id, OLD.item_id, OLD.quantity, OLD.created);
    RETURN OLD;
END;
$$ LANGUAGE plpgsql;
CREATE TRIGGER trigger_cart_items_delete BEFORE DELETE ON items FOR EACH ROW EXECUTE FUNCTION cart_items_soft_delete();
-- https://github.com/IanWold/PostgresRefactorSoftDelete/blob/main/SeparateTableMigration.cs#L29
CREATE OR REPLACE FUNCTION items_soft_delete() RETURNS TRIGGER AS $
BEGIN
    INSERT INTO items_deleted (item_id, name, price, created)
    VALUES (OLD.item_id, OLD.name, OLD.price, OLD.created);
    RETURN OLD;
END;
$ LANGUAGE plpgsql;
CREATE TRIGGER trigger_items_delete BEFORE DELETE ON items FOR EACH ROW EXECUTE FUNCTION items_soft_delete();
CREATE OR REPLACE FUNCTION carts_soft_delete() RETURNS TRIGGER AS $
BEGIN
    INSERT INTO carts_deleted (cart_id, user_id, created)
    VALUES (OLD.cart_id, OLD.user_id, OLD.created);
    RETURN OLD;
END;
$ LANGUAGE plpgsql;
CREATE TRIGGER trigger_carts_delete BEFORE DELETE ON carts FOR EACH ROW EXECUTE FUNCTION carts_soft_delete();
CREATE OR REPLACE FUNCTION cart_items_soft_delete() RETURNS TRIGGER AS $
BEGIN
    INSERT INTO cart_items_deleted (cart_item_id, cart_id, item_id, quantity, created)
    VALUES (OLD.cart_item_id, OLD.cart_id, OLD.item_id, OLD.quantity, OLD.created);
    RETURN OLD;
END;
$ LANGUAGE plpgsql;
CREATE TRIGGER trigger_cart_items_delete BEFORE DELETE ON items FOR EACH ROW EXECUTE FUNCTION cart_items_soft_delete();
-- https://github.com/IanWold/PostgresRefactorSoftDelete/blob/main/SeparateTableMigration.cs#L29 [tl! autolink]

You then have the same considerations regarding cascades and foreign key references as you had in the last refactor option. I'll leave that as an exercise for you to extend the trigger functions to include that behavior.

Accessing Deleted Records #

This is either the benefit or the drawback of this setup compared to the first scheme. In order to access deleted records, you query the _deleted table:

SELECT * FROM items_deleted WHERE ...
-- https://github.com/IanWold/PostgresRefactorSoftDelete/blob/main/SeparateTableMigration.cs#L58
SELECT * FROM items_deleted WHERE ...
-- https://github.com/IanWold/PostgresRefactorSoftDelete/blob/main/SeparateTableMigration.cs#L58 [tl! autolink]

And of course all records together from the separate view:

SELECT * FROM items_combined WHERE ...
SELECT * FROM items_combined WHERE ...

If your application will need to regard these three sets differently in distinct queries, then this setup is advantageous: there's less chance of writing the queries incorrectly and causing bugs. However, if you do need to consult the blended data or perform mostly the same queries, the first option might be better.
